USB BT v.5.0 dongle

BTD-MINI6

USB BT v.5.0 dongle

BTD-MINI6

ENJOY THE FREEDOM OF WIRELESS TECHNOLOGY
Large operating distance
Easily connect any BT device to your PC
Fast & easy file transfer between your PC and mobile devices
Perfect for streaming high quality stereo music
Windows 11 compatible

USB mini sized BT 5.0 dongle
Allows connecting BT keyboards, mice, speakers, phones, tablets, etc to your PC
Up to 20 m operating distance
BT 5.0 - high-speed data transfer and low power consumption
Suitable for streaming high quality stereo music

Interface: USB 2.0
BT specification: v.5.0, downwards compatible with v.4.0 or older, Realtek chipset
Frequency band: 2.402 - 2.48 GHz ISM
Power: class II, RF power up to 6 dBm (max. EIRP), sensitivity -86 dBm,
Working distance: up to 20 m (in the open air)
Antenna type: internal antenna, gain in dBi (typical): 0.8 dBi
Power supply: 5 VDC up to 22 mA
Dimensions: 29 mm x 17 mm x 8 mm
Net weight: 3 g

Windows 10/11
Free USB port

CE Certificate (pdf file)

Hi-Res photos

hi-res photo (278 kb)

hi-res photo package (3469 kb)

Web Site images

website image (309 kb)

website image (27 kb)

web package image (257 kb)

website image (390 kb)

website image (393 kb)

website image (378 kb)

Helpdesk Email helpdesk@gembird.nl (Monday to Friday from 9:00 AM to 5:00 PM (NL time) excluding holidays)

manual (603 kb)

Helpdesk Email helpdesk@gembird.nl (Monday to Friday from 9:00 AM to 5:00 PM (NL time) excluding holidays)

driver BTD-MINI6_5.0 driver (RTL8761B, win7-8-10-11) (75491 kb)

Packing details
Q'ty in crtn, pcs	400
Crtn volume, CUM	0.070278
Crtn weight, kgs	11.5
Individual package size LxWxH:	105x10x134 mm
Carton size LxWxH:	530x390x340 mm
Country of origin	CN
Barcode	8716309126724
Customs code	8522900090
Packaging	color box
